• Modular design for easy battery assembly, hanging design for easy solar panel installation.
• Built-in high-safety, high-reliability, and long-life lithium battery cell is suitable for a wide range of application scenarios.
• Built-in self-developed high-efficiency solar controller realizes faster charging.
• Visual status indicator allows for easy understanding of the product’s operating status.
• Multiple protection functions such as high and low battery temperature protection, overcharge protection, undervoltage protection, etc.
• Metal casing, windproof and rainproof, capable of withstanding harsh outdoor environments.
• Built-in heating module can be turned on in a low temperature environment, effectively protecting the battery life and ensuring the safety of charging.
Login/Register
2 in stock
Pick up from the Store selected at Check Out. Items should be paid for and collected as soon as transaction is done, subject to cancellation if not collected within 5 days.
Free
Delivery Service Within 5 working days
Free
To be negotiated with your habitual Sales Representative for orders above Rs. 25,000
Warranty Period and services offered are as per Manufacturer's Terms SLR-R200-H-IN
| Specification | ||||||||
| Battery capacity | 100Ah | |||||||
| Rated energy | 320Wh | |||||||
| Limited charge voltage | 7V | |||||||
| Output voltage | 9V to 12.6V | |||||||
| Maximum output current | 2A | |||||||
| Input interface type | 4-pin quick connector (for battery switch) | |||||||
| Output interface type | DC12V circular connector | |||||||
| RS485 | Support | |||||||
| Operating temperature | -20 ℃ to 55 ℃ (discharge)-20 ℃ to 45 ℃ (charge) | |||||||
| Dimensions | 419.2*118*336.5mm | |||||||
| Weight | 4.6kg | |||||||
| Protection function | High/low temperature protection, overcharge protection, undervoltage protection | |||||||
| General | ||||||||
| Suitable pole diameter | 67mm to 110 mm | |||||||
Overview | Brand |
UNV |
|---|
