Warranty Period and services offered are as per Manufacturer's Terms Door station/System parameters | |
| Operation system
| Embedded Linux operation system
|
| Flash
| 32 M
|
| RAM
| 256 M
|
Door station/Video parameters | |
| Supplement light
| IR supplement |
| Resolution | Main stream : 1920 × 1080p, 1280 x 720p Sub stream : 1280 x 720p, 640 × 480p
|
| Lens
| 1 |
| WDR | Support |
| FOV
| Horizontal: 124° Vertical: 75°
|
| Video compression standard | H.264; h.265; MJPEG |
Door station/Audio parameters | |
| Audio input
| Built-in omnidirectional microphone
|
| Audio output | Built-in loudspeaker (more than 80 dB within 30 cm) |
| Volume adjustment | Adjustable
|
| Audio compression standard | G711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
|
| Audio compression Rate
| 64 Kbps |
| Audio quality
| Noise suppression and echo cancellation
|
Door station/Capacity parameters | |
| User capacity | 2000 |
Door station/Network parameters | |
| Network protocol
| TCP/IP, RTSP
|
| Wi-Fi
| Wi-Fi 802.11 b/g/n
|
| Wired network
| 10/100 Mbps self-adaptive Ethernet |
| 3G/4G
| /
|
| Bluetooth
| /
|
Door station/Device interfaces | |
| Network interface
| 1
|
| RS-485
| 2
|
| Lock control
| 2 |
| Exit button
| 2 Max. |
| Door contact
| 2
|
| Alarm input
| 4
|
| Alarm output
| 0
|
| Power interface
| 1
|
| TAMPER
| 1
|
| TF card
| 1 (reserved) |
Door station/General | |
| Button
| 1
|
| Indicator
| 3
|
| Power consumption
| 10 W
|
| Power supply
| IEEE802.3af, standard PoE 12 VDC
|
| Working temperature
| -40° C to 53° C(-40° F to 127.4° F) |
| Working humidity
| 10% to 95%
|
| Dimension
| 174 mm × 91 mm × 29 mm
|
| Installation
| Surface mounting |
| Application environment
| Outdoor
|
| Protection level
| IP65, IK08 380 g
|
Indoor station/System parameters | |
| Operation system
| Embedded Linux operation system
|
| Memory
| 128 MB
|
| Flash
| 32 MB
|
Indoor station/Display parameters | |
| Display screen
| 7-inch colorful TFT screen
|
| Display resolution
| 1024 × 600 |
| Operation method
| Capacitive touch screen
|
Indoor station/Audio parameters | |
| Network interface
| 1 RJ-45 10/100 Mbps self-adaptive
|
| Wired network
| 10/100 Mbps self-adaptive
|
| Wireless network
| Wi-Fi 802.11 b/g/n
|
| Protocol
| TCP/IP, SIP, RTSP
|
Indoor station/Device interfaces | |
| RS-485
| 1
|
| Alarm input
| 8-ch alarm inputs
|
| Relay output
| 2
|
| TF card
| Max to 32 G, SD 2.0 or lower version
|
Indoor station/General | |
| · Power consumption
| ≤ 6 W
|
| Power supply
| Standard PoE,12VDC
|
| Working temperature | 10 °C to 55 °C (14 °F to 131 °F) |
| Working humidity | 10% to 90% |
| Dimension(L x W x H)
| 200 mm × 140 mm × 15.1 mm (7.9″ × 5.5 × 0.6″)” |
Overview | Brand |
Hikvision |
|---|
